HB-7231AF

naya sadak newroad, New Road, Kathmandu

Available

1 years ago

2033-01-05

SOMMAIRE 1/2 Cat.6 U/UTP LSZH cable for local networks Fiche technique : S000099460EN-03 Mise à jour le : 02/02/2021 Créée le : 19/06/2017 Catalogue number(s) : 0 327 54 128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex Tel : 0 (+33) 5 55 06 87 87 Fax : 0 (+33) 5 55 06 88 88 www.legrand.com 1. USE Cable for high-speed VDI transmission networks 802.3 bt PoE++ up to type 4 applications compatible according to installation standards ISO/IEC 14763-2 : 2019 and EN 50174-2 : 2018 2. DESCRIPTION X-shaped separator Insulation: solid PE Pair Copper Protection: LSZH sleeve MARKING AND PACKAGING Marking of Legrand cables - LEGRAND - Catalogue number - Number of pairs - Gauge - Type - Impedance - Type of sleeve - Category - Conformity to standards - EUROCLASS - Velocity of propagation - Traceability - Measurement (remaining length in metres). Complementary marking (on label) - Designation - Made in.... 3. PERFORMANCE AT 250 MHZ (STAND. ANSI/TIA 568.2-D) Reference 0 327 54 Maximum attenuation (dB/100 m) 32,8 Minimum NEXT (dB) 38,3 PS NEXT (dB) 36,3 ACRF (dB/100 m) 19,8 PS ACRF (dB/100 m) 16,8 Return Loss (dB) 17,3 4. TECHNICAL AND MECHANICAL FEATURES Catalogue number 0 327 54 Type U/UTP Type of sleeve LSZH Number of pairs 4 Assembly Pairs Diameter over insulation (mm) 0,99 ± 0,04 Average nominal diameter of the cable (mm) 5,8 ± 0,4 Weight of cable (kg/km) 37 to 43 Min. bending radius when laying (mm) 25 AWG gauge* 23 * According to UL 444 ed.3 table 4 5. ELECTRICAL FEATURES AT 20°C SOMMAIRE 2/2 Cat.6 U/UTP LSZH cable for local networks Fiche technique : S000099460EN-03 Mise à jour le : 02/02/2021 Créée le : 19/06/2017 Catalogue number(s) : 0 327 54 Catalogue number 0 327 54 Type U/UTP Maximum linear resistance (ohm/km) 95 * DC dielectric strength 1 KV / 1 min * Minimum insulation resistance (Mohm.km) 5000 Minimum propagation speed 66 % Characteristic impedance at 100 MHz 100 ±5O * According to standard IEC 61156-5 6. ORDERING INFORMATION Catalogue number 0 327 54 Type U/UTP Colour Blue RAL 5015 Pack (m) 305 Packaging Box 7. ENVIRONMENTAL FEATURES Transport and storage temperature: -20 at + 60 °C Storage temperature before installation: 10°C during 24h (if stock = 5°C ) Usage temperature: – 20 to + 60 °C Fire rating:EN 50399, IEC 60332-1-2, EN 60332-1-2 Smoke density : IEC 61034-2, EN 61034-2 Toxicity of fire effluent : IEC 60754-2, EN 60754-2 EUROCLASS EN 13501-6 = Class Dca s2d2a1 Also compliant with Eca 8. STANDARDS AND APPROVALS Cat 6, 250 MHz Electrical performances and characteristics : - ANSI/TIA 568.2-D - EN 50173-1 - EN 50288-6-1 - ISO/IEC 11801 (ed. 2.2) - IEC 61156-5 IEEE 802.3bt : PoE++

365days

Anywhere

100-1500
