Used For
Camera Image Sensor 1/3 Progressive Scan CMOS sensor Day and Night ICR type Bracket Angle Adjustment / Lens Focal Length 4 mm Aperture F1.6 FOV Horizontal FOV: 83°, Vertical FOV: 44°, Diagonal FOV: 98.6° Illuminator Supplementary Light 2 IR Lights, 2 Spotlights Supplementary Light Distance Up to 30 m/100 ft (depending on environment) IR Wavelength 850nm Night Vision Mode Smart Mode, Full Color Mode, Black & White Mode Video Video Encoding Format H.265, H.264 Main Stream Resolution 2560 ×1440, 2304 ×1296, 1920 × 1080, 1280 × 720 Sub Stream Resolution 640 × 360, 352 × 288 Frame Rate 1-30fps, Default 20fps Bit Rate 512kbps -- 4096kbps Bit Rate Control CBR,VBR Audio Audio Encoding Format G.711A, G.711U, AAC Audio Sampling Rate 8 kHz Audio Communication Two-way Audio, Voice Input Image Image Enhancement DWDR, BLC, HLC, 3D DNR Privacy Mask 4 Areas Network Ethernet Port 1 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet port ONVIF Support Protocols TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP, WebSockets Web Browser Plug-in free live view: Chrome, Edge, Opera Pan&Tilt Pan Movement Range 0°--355° Tilt Movement Range 0°--90° Preset 6 Patrol Panoramic Patrol, Preset Patrol Wi-Fi Antenna Dual external antennas Wireless Standard IEEE 802.11 b/g/n Transmission Rate Up to 300 Mbps Channel Width 20/40 MHz Modulation DSSS/OFDM Frequency Band 2.4GHz: 2412MHz-2472MHz(CH1-CH13) Transmit Power 2.4GHz: <0.092W(EIRP) Sécurité 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK Alarm Smart Detection Motion Detection, Tempering Detection, Human Detection, Vehicle Detection Smart Linkage Sound&light Alert, Human Tracking DIY Audio 3 Customized Audios Interface Audio Input Built-in MIC Audio Output Built-in Speaker Storage Built-in Micro SD Card Slot, Up to 256 GB Reset Button Support LED Indicator Dual Color (red & blue) LED Indicator General Power 12 V DC, 1A, Ø5.5mm&Ø2.1mm Power Plug Material Plastic Smart Integration Amazon Alexa Product Dimension 138 mm x 120 mm x 187 mm (5.4 × 4.7 × 7.4) Package Dimension 167 mm x 131 mm x 251 mm (6.6 × 5.2 × 9.9) Product Weight 426g (0.94lb) With Package Weight 840g (1.85lb) Protection Level IP65 Installation Method Wall Mounting, Ceiling Mounting, Pole Mounting Certification CE, RoHS, FCC, RCM, UKCA Température Operating Temperature: -30°C ~ 60°C (-22°F ~ 140°F) Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) Humidité Operating Humidity: 10% ~ 95% RH (non-condensing) Storage Humidity: 3% ~ 95% RH (non-condensing) Contenu du colis Camera Power Adapter (cord length: 3m) Installation Template Mounting Bracket Mounting Accessories Kit Waterproof Kit Quick Installation Guide
